The lighty.io RESTCONF-NETCONF (RNC) application allows to easily initialize, start and utilize the most used OpenDaylight services, including clustering and optionally add custom business logic. PANTHEON.tech provides a pre-prepared Helm chart inside the lighty.io RNC application, which can be easily used for Kubernetes deployment.

Clustering is a mechanism that enables multiple processes and programs to work together as one entity.

For example, when you search for something on google.com, it may seem like your search request is processed by only one web server. In reality, your search request is processed by many web servers connected in a cluster. Similarly, you can have multiple instances of OpenDaylight working together as one entity.

The advantages of clustering are:

• Scaling: If you have multiple instances of OpenDaylight running, you can potentially do more work and store more data than you could with only one instance. You can also break up your data into smaller chunks (shards) and either distribute that data across the cluster or perform certain operations on certain members of the cluster.
• High Availability: If you have multiple instances of OpenDaylight running and one of them crashes, you will still have the other instances working and available.
• Data Persistence: You will not lose any data stored in OpenDaylight after a manual restart or a crash.

This article demonstrates, how to configure the lighty.io RNC application to use clustering, rescaling of the cluster and connecting a device to the cluster.

Add the PANTHEON.tech Helm Repository to MicroK8

For deploying the lighty.io RNC application, we will use and show how to install the microk8s Local Kubernetes engine. Feel free to use any other of your favorite local Kubernetes engines, which you have installed.

1. Install microk8s with snap.

sudo snap install microk8s --classic
sudo usermod -a -G microk8s $USER
sudo chown -f -R $USER ~/.kube

2. Enable the required add-ons.

microk8s enable dns helm3

3. Add the PANTHEON.tech Helm repository to microk8s.

microk8s.helm3 repo add pantheon-helm-repo https://pantheontech.github.io/helm-charts/

microk8s.helm3 repo update

microk8s.helm3 install lighty-rnc-app pantheon-helm-repo/lighty-rnc-app-helm --version 16.1.0 --set lighty.replicaCount=3,lighty.akka.isSingleNode=false,nodePort.useNodePort=false,lighty.moduleTimeOut=120

microk8s.helm3 ls

image:
  name: ghcr.io/pantheontech/lighty-rnc
  version: 16.1.0
  pullPolicy: IfNotPresent

microk8s.helm3 install lighty-rnc-app pantheon-helm-repo/lighty-rnc-app-helm --version 16.1.0 --values [VALUES_YAML_FILE]

microk8s.kubectl get pods

sudo docker build -t lighty-netconf-simulator .

sudo docker run -d --rm --name netconf-simulator -p17830:17830 lighty-netconf-simulator:latest

docker inspect -f '{{range.NetworkSettings.Networks}}{{.IPAddress}}{{end}}' netconf-simulator

microk8s.kubectl get pods -l app.kubernetes.io/name=lighty-rnc-app-helm -o custom-columns=":status.podIP"

curl  --request GET 'http://[HOST_IP]:8558/cluster/members/'

{
    "leader": "akka://opendaylight-cluster-data@10.1.101.177:2552",
    "members": [
        {
            "node": "akka://opendaylight-cluster-data@10.1.101.177:2552",
            "nodeUid": "4687308041747729846",
            "roles": [
                "member-10.1.101.177",
                "dc-default"
            ],
            "status": "Up"
        },
        {
            "node": "akka://opendaylight-cluster-data@10.1.101.178:2552",
            "nodeUid": "-29348997399314594",
            "roles": [
                "member-10.1.101.178",
                "dc-default"
            ],
            "status": "Up"
        }
    ],
    "oldest": "akka://opendaylight-cluster-data@10.1.101.177:2552",
    "oldestPerRole": {
        "member-10.1.101.177": "akka://opendaylight-cluster-data@10.1.101.177:2552",
        "dc-default": "akka://opendaylight-cluster-data@10.1.101.177:2552",
        "member-10.1.101.178": "akka://opendaylight-cluster-data@10.1.101.178:2552"
    },
    "selfNode": "akka://opendaylight-cluster-data@10.1.101.177:2552",
    "unreachable": []
}

curl --request PUT 'http://[HOST_IP]:8888/restconf/data/network-topology:network-topology/topology=topology-netconf/node=new-node' \
--header 'Content-Type: application/json' \
--data-raw '{
    "netconf-topology:node": [
        {
            "node-id": "new-node",
            "host": [DEVICE_IP],
            "port": 17830,
            "username": "admin",
            "password": "admin",
            "tcp-only": false,
            "keepalive-delay": 0
        }
    ]
}

curl --request GET 'http://[MEMBER_1_IP]:8888/restconf/data/network-topology:network-topology/topology=topology-netconf/node=new-node'
curl --request GET 'http://[MEMBER_2_IP]:8888/restconf/data/network-topology:network-topology/topology=topology-netconf/node=new-node'
...

{
    "network-topology:node": [
        {
            "node-id": "new-node",
            "netconf-node-topology:connection-status": "connected",
            "netconf-node-topology:username": "admin",
            "netconf-node-topology:password": "admin",
            "netconf-node-topology:available-capabilities": {
                "available-capability": [
                    {
                        "capability": "urn:ietf:params:netconf:base:1.1",
                        "capability-origin": "device-advertised"
                    },
                    {
                        "capability": "urn:ietf:params:netconf:capability:notification:1.0",
                        "capability-origin": "device-advertised"
                    },
                    {
                        "capability": "urn:ietf:params:netconf:capability:candidate:1.0",
                        "capability-origin": "device-advertised"
                    },
                    {
                        "capability": "urn:ietf:params:netconf:base:1.0",
                        "capability-origin": "device-advertised"
                    },
                    {
                        "capability": "(urn:ietf:params:xml:ns:yang:ietf-inet-types?revision=2013-07-15)ietf-inet-types",
                        "capability-origin": "device-advertised"
                    },
                    {
                        "capability": "(urn:opendaylight:yang:extension:yang-ext?revision=2013-07-09)yang-ext",
                        "capability-origin": "device-advertised"
                    },
                    {
                        "capability": "(urn:tech.pantheon.netconfdevice.network.topology.rpcs?revision=2018-03-20)network-topology-rpcs",
                        "capability-origin": "device-advertised"
                    },
                    {
                        "capability": "(urn:ietf:params:xml:ns:yang:ietf-yang-types?revision=2013-07-15)ietf-yang-types",
                        "capability-origin": "device-advertised"
                    },
                    {
                        "capability": "(urn:TBD:params:xml:ns:yang:network-topology?revision=2013-10-21)network-topology",
                        "capability-origin": "device-advertised"
                    },
                    {
                        "capability": "(urn:ietf:params:xml:ns:yang:ietf-netconf-monitoring?revision=2010-10-04)ietf-netconf-monitoring",
                        "capability-origin": "device-advertised"
                    },
                    {
                        "capability": "(urn:opendaylight:netconf-node-optional?revision=2019-06-14)netconf-node-optional",
                        "capability-origin": "device-advertised"
                    },
                    {
                        "capability": "(urn:ietf:params:xml:ns:netconf:notification:1.0?revision=2008-07-14)notifications",
                        "capability-origin": "device-advertised"
                    },
                    {
                        "capability": "(urn:opendaylight:netconf-node-topology?revision=2015-01-14)netconf-node-topology",
                        "capability-origin": "device-advertised"
                    }
                ]
            },
            "netconf-node-topology:host": "172.17.0.2",
            "netconf-node-topology:port": 17830,
            "netconf-node-topology:tcp-only": false,
            "netconf-node-topology:keepalive-delay": 0
        }
    ]
}

microk8s.kubectl get pods

microk8s.kubectl get pod [NAME] -o custom-columns=":status.podIP" | xargs

microk8s.kubectl delete -n default pod [LEADER_NAME]

microk8s.kubectl get pods

6. Verify, that a new leader was elected

curl  --request GET 'http://[HOST_IP]:8558/cluster/members/'

{
    "leader": "akka://opendaylight-cluster-data@10.1.101.178:2552",
    "members": [
        {
...

As a result of deleting the pod, a new leader was elected from the previous pods.

7. Verify that the new pod also contains the device. The response should be the same as in step 4.

curl --request GET 'http://[NEW_MEMBER_IP]:8888/restconf/data/network-topology:network-topology/topology=topology-netconf/node=new-node'

8. Delete the device

curl --request DELETE 'http://[HOST_IP]:8888/restconf/data/network-topology:network-topology/topology=topology-netconf/node=new-node'

9. Verify that the testing device was removed from all cluster members

curl --request GET 'http://[MEMBER_1_IP]:8888/restconf/data/network-topology:network-topology/topology=topology-netconf'
curl --request GET 'http://[MEMBER_1_IP]:8888/restconf/data/network-topology:network-topology/topology=topology-netconf'
...

Your response should look like this:

{
    "network-topology:topology": [
        {
            "topology-id": "topology-netconf"
        }
    ]
}

10. Logs from the device can be shown by executing this command:

sudo docker logs [CONTAINER ID]

11. Logs from the lighty.io RNC app can be shown by executing the following command:

microk8s.kubectl logs [POD_NAME]

This post explained how to start a containerized, lighty.io RNC application and configure it to use clustering. Furthermore, an explanation of how to make your own cluster configuration either from a file or using –set flag was shown, to set the size of the cluster to your liking.  Rescaling of the cluster and connecting a simulator device to the cluster was also shown and explained.
